From 600€

From 600€

This combination does not exist.


Provided by HEAD Aerospace



cloudeo Terms and Conditions

Take advantage of the onboard intelligent processing system of HEAD Aerospace with 25 spectral bands (from coastal blue, to chlorophyll and biomass) up to 3m resolution!

Archive

starts from

600

  • Already available imagery from HEAD Aerospace catalogue
  • Global coverage
  • Minimum order size 25km², minimum area width 5km

Tasking - Standard

starts from

6000

  • Order new imagery over your area of interest
  • Tasking window of up to 90 days
  • Cloud coverage up to 15%
  • Minimum order size 100km², minimum area width 5km

Tasking - Priority

starts from

7800

  • Order new imagery over your area of interest
  • Tasking window of up to 1 week
  • Cloud coverage up to 15%
  • Minimum order size 100km², minimum area width 5km

Tasking - Emergency

starts from

9000

  • Order new imagery over your area of interest
  • Tasking window of up to 3 days
  • Minimum order size 100km², minimum area width 5km

Interested in HyperScan imagery?

Fill out a form with all your requirements and we will contact you as soon as possible with a quote!

HyperScan

Hyperscan (JL-1GP01/02) satellite has a 110 Km Swath and 25 bands starting from 5 m resolution including Coastal-band, RGB, Red-edge, NIR, SWIR, MWIR, and the thermal LWIR. It is twice the spectral and spatial resolution of Sentinel 2. This satellite is suited for large-scale agriculture monitoring with two days revisit, and with a rich archive over the last two years.

HyperScan is carried onboard the Jilin-1 GP01 and Jilin-1 GP02 Earth Observation (EO) satellites, which were both launched on 21 January 2019 from the Jiuquan Satellite Launch Centre in China. The two satellites are equipped with multi-spectral imagers, short-wave, medium-wave, and long-wave infrared cameras, the "Shuiyun-1" system, and other payloads.

Both satellites are also equipped with onboard intelligent processing systems, which can generate remote sensing data with a resolution of 3m, a width of 110km, and at 25 different spectral bands. This data collection of a high number of bands from a combination of Visible Near-Infrared (VNIR), Shortwave, Mediumwave, and Longwave Infrared imagers, makes HyperScan comparable to hyperspectral products.

Some general information for HEAD Aerospace HyperScan imagery:

Constellation
HyperScan

Launch

2019 (JL-1GP01, JL-1GP02)

Spectral bands

B0-B19: 450-1040nm

SW1:1195-1225nm
SW2:1360-1390nm
SW3:1550-1590nm
SW4:1610-1690nm

MWIR:3700 nm~4950nm

LWIR:7500nm~13500nm

Spatial resolution

B0~B6 (nadir): 5 m
B7~B12 (nadir): 10 m
B13~B19 (nadir) : 20 m
B3~B5 (nadir): 3 m

SW1~SW4, MWIR (nadir): 100 m

LWIR:150m

Geometric precision

<8.5m (CE90)

Radiometric resolution

B0~B19: 12 bits
SW1~4,MWIR,LWIR: 14bit

Revisit time

2 days
Swath width
110 km
OrbitSun-synchronous
10:30 AM descending node
528 km altitude


Key features

Combination of Visible Near-Infrared (VNIR), Shortwave, Mediumwave, and Longwave Infrared imagers

Medium-resolution satellite imagery since 2019, up to 3 meters

110 km swath capable of continuous imaging

Capture any area or point of interest around the world

Satellite tasking capability to meet your project requirements

25 spectral bands (from coastal blue to chlorophyll and biomass

Key applications

Agriculture

Water management and irrigation planning

Insurance claim analysis

Post-disaster assessment (floods, drought)

Marine

Pollution detection

Coastal and inland water quality monitoring at regional and country level

Oil spill detection and monitoring

Infrastructure

Post-disaster management

Search and rescue operations

Estimate green area coverage within urban environments

FAQs

The minimum order for HyperScan imagery is 25 km² for Archive and 100 km² for New tasking, with minimum AOI width of 5km.

Request quote

Protected by reCAPTCHA,  I have read and accept the Privacy Policy

People also viewed

Do you have more questions about the product?

We are here for you! Please contact us and we will come back to you shortly!

Specifications for HyperScan

General Info
Service Provider​ HEAD Aerospace
Thematic Information Multispectral Satellite Imagery
Service Option​s 25 bands; Archive; Priority Tasking
Features​ Provided Cloud cover selection; End User licenses
Access Mode​ File transfer; API
Pricing Options Pre-paid
Pricing​ Per km²; min. order 500km² for Archive; min. 2500km² for Tasking; min AOI width 10km
Free Trial On demand
Delivery Time​ Up to 5 business days
Compatible products Standalone; SaaS
Geodata Specs
Mission HyperScan (Jilin-1)
Sensor & Data Products MSI
Data Processing Level L1
Data Format​ GeoTIFF; 12bit B0-B19; 14bit SW1-4, MWIR, LWIR
Spectral Bands RGB; SW; MWIR; LWIR
Spatial Resolution​ 3m RGB; 5m B0-B6; 10m B7-B12; 20m B13-B19; 110 km Swath width
Spatial Coverage Global
Temporal Coverage Since 2019
Temporal Resolution 2 days
Accuracy <8.5m (CE90)
